| 80W Solar Light Head : |
|
420W Solar Hexagonal : |
|
| Model No ： EA-T80W |
Hexagonal module no.: G140W 3Pcs |
| Body material : aluminium die cast |
Peak power: 420W |
| LED power: 80W |
|
Peak vol & current :36V 11.67A |
| LED type : 248nos Philips SMD3030 |
Module quantity : 3 Pcs |
| Beam angle : 145*83° |
|
Module size : 200*228*1560mm |
| Luminous flux : >10,800lm |
|
Soalr cell Type : MONO |
| Color temperature : 6000K |
|
Warranty : 5 Years |
|
| Battery capacity: 1080WH 24V |
Lifetime : > 20 Years |
|
| Lifetime :> 2500 Cycles |
|
| Solar controller : MPPT or |
10M Steel Pole : |
|
| Hybrid / Wireless Intelligent Control |
Height : 10 Meters |
|
| Charging time : 5 Hours |
|
Top / Bottom Size: 100mm / 190mm |
| Battery autonomy : 3~5 Days |
|
Thickness : 4mm |
|
| Operating tem. : -20°C ~ 65°C |
Hot dip galvanized and |
|
| IP rate: IP67 |
|
Podwer coated treatment |
| Warranty : 5 Years |
|
|
